CSS-3 Allied (TA) Style Replaceable Spade Drill

Allied (TA) style replaceable spade drill featuring interchangeable spade bits for high-performance hole-making. Available in M4/T15/M48 high-speed steel and C2/C3/C5 carbide grades to cover a broad range of workpiece materials from aluminum and cast iron to hardened steels and titanium alloys.

Style

Allied (TA) Style

Bit Type

Replaceable Spade Bit

HSS Grades

M4, T15, M48

Carbide Grades

C2, C3, C5

Quantity:

Made in USAISO 900124-Hour Quote Turnaround

Technical Specifications

Specification	Value
Style	Allied (TA) Style
Bit Type	Replaceable Spade Bit
Hss Grades	M4, T15, M48
Carbide Grades	C2, C3, C5
Coating Options	TiN, TiCN, TiAlN, Uncoated
Application	General Machining, Cast Iron, Steel, Stainless, Non-Ferrous
Shank Type	Straight Shank / Weldon Flat
Coolant Through	Yes — available on select holders
Tolerance Class	H7 / H8
Compatibility	TA Style Spade Drill Bodies
